Hexa-cover® Floating cover is an effective emission and evaporation coltrol for oil & GAS

​The unique and patented Hexa-Cover® Floating Cover is perfect for almost any type of Oil & Gas and API applications.

​

The Hexa-Cover® Oil & Gas / API products has proven to be an effective and efficient option for hot heavy oil duty applications such as CHOPS, Diluted Bitumen SAGD.​

​

Hexa-Cover® OIL & Gas Duty:

  • Reduce emissions such as BTEX benzene, Toluene, Ethylbenzene and Xylene. Eliminate or reduce water vapour that act as a carrier of VOCs that add to odour problems
  • Reduce heat loss resulting in lower operating costs. Insulation for liquid surface in a heated crude oil tank lowers operating costs for CHOPS facilities and central processing batteries.
  • Reduce offensive and carcinogenic BTEX odours.
  • Reduce tank head space corrosion by lower levels of humidity above the liquid level.
  • Reduce or possibly eliminate expensive defoaming chemicals.
  • Reduce energy needed to reach optimum process temperatures.
  • Reduce the amount of water vapour generated as steam. Steam causes icing of the thief hatch and the transport of other odours from the tank.

Hexa-Cover® OIL & Gas Duty:

  • Chemically compatible with heavy oil components up to temperatures of 100 °C and for SAGD dilbit sales tanks
  • Resistant to weight gain
  • Polymer is anti-static surface with a value of 3.7 x 1009 Ω
  • Resistant to thermal shock. Tested at -40 °C to +100 °C for sudden rapid temperature exposure
  • Can be installed while existing tanks are in operation

Oil & Gas Applications for Hexa-Cover® Products

  • Conventional Crude Oil
  • Frac Oil
  • Gasoline, Diesel and other Refined Products
  • Thermal Heavy Oil
  • SAGD Dilbit Sales Tanks
  • Sour Sand Slurry Tanks
  • Process Water Ponds
  • Purified Tailings Ponds
  • Frac Water Tanks
  • API Separator
  • Hydrocarbon contaminated water

​

Specifications, Hexa-Cover® Oil & Gas Duty

  • Diagonal measure: 21 cm +/- .32cm
  • Height: 8.38cm +/- .127 cm
  • Weight: 286g +/- 16g
  • Density: 0.375g/cc (+2 / -1%)
  • Plate thickness at sphere 1.78cm
  • Plate thickness at outer perimeter 1.14 +/- .127cm

Link: Hexa-Cover® Oil & Gas / API flyer

​Link: Installation Map

Link: Single Tank Thief Hatch

Link: Side Door / Door Pull

Link: Multi-Tank Installation, Vertical Overflow

Link: DuPont™ show case Hexa-Cover® Oil & Gas​

Link: Hexa-Cover® Oil & Gas Duty - Press release​
​

For more info on Hexa-Cover® Oil & Gas / API please contact;

​

Mr. Søren Madsen
TEL +45 96 17 78 00
CELL +45 29 33 79 72
[email protected]​
www.hexa-cover.com​
